RGB LED Light: Standard Under Fender Multicolor RGB LED.
Length: 25.6 inches (650mm) Width: 10.04 inches (255mm) Wheelbase: 16.02 inches (407mm) Ground Clearance: 3.54inch (90mm) Weight: 5.51 lb. 2.5 kg Recommended Battery: 2S 5000mAh LiPo Battery with dean connector
RGB LED Light: Standard Under Fender Multicolor RGB LED.
ESC: 40A WP-1040-Brushed (By HobbyWing)
- Water-Proof and Dust-Proof for All Weather.
- Built-In Capacitor Module.
- Automatic Throttle Range Calibration.
- Low Voltage Cut-Off Protection for Li-Po and NiMH Battery.
- Over-Heat Protection and Throttle Signal Loss Protection.
Motor: RS-540 High Torque Brushed Motor.
Servo: 12Kg Metal Gear Servo (By Savox)
- 4.8V - 0.26 sec/60 10.0 kg-cm.
- 6.0V - 0.23 sec/60 12.0 kg-cm.
- 25T Horn Gear Spline.
Radio System: Pistol-Grip Mod-3S 3 Channel Transmitter and Receiver
- Digital Trimming.
- Steering Dual-Rate (ST D/R) Adjustment.
- End Point Adjustment (EPA).
- Build in Failsafe.
- Frequencies: 2.4GHz
- Power Supply: 4
- AA Alkaline (Not Included).
Body: Official Licensed by Ford Motor
- F-250 Super Duty.
- Scale Realistic Body Details.
- Black Bed Liner Coating.
- hard Molded Front & Rear bumpers with build in 3mm LED housing
Chassis:
- Steel Frame Rails.
- CMS (Chassis Mounted Servo) Chassis Design.
- Stamped Steel Shock Hoops.
- Steel Skid Plate.
- Full Precision Ball Bearing Supported.
- Adjustable Turnbuckles.
- High Torque Servo Saver Horn.
- Easy Access Battery Tray.
- Battery Tray Size 146 x 50 x 25mm.
Suspension:
- Custom Lifted Suspension Design.
- 110mm Big Bore Oil Filled Adjustable Coil Over Shocks.
- 12mm over size shock body with 3mm Hardened Steel Polished Shaft.
- Harden Steel Steering Drag Link.
- CNC Machined 6mm Aluminum Linkage.
- Front / Rear Sway Bar.
Drivetrain:
- Full Metal Transmission Gears.
- 4 Wheels Drive.
- Center Shaft Drivetrain for More Power Transferred to the Wheels.
- Hight Efficient Transmission System.
- Wide Range Easy Changeable Gear Box Design.
- Sealed Transmission Case.
- Sealed Axle Housing.
- Metal Planetary Gear Type Differential.
Gear Ratio:
- Hi / Speed Ratio 1.56:1
- Hi / Torque Ratio 2.8:1
- Spur / Pinion Gear 32p85/32p12T
- Ring & Pinion Gear30/15T 2:1
Wheel: Official Licensed by KG1 Forged
- KF004 Vile Wheel.
- 66.50mm x 37.5mm.
Tires: Official Licensed Fury Tires
- Low Profile Country Hunter tires.
- 65 x 100.50 x 38.50 mm.
Specifications:
