The Team Corally CERIX II RS-160 "RACING FACTORY" electronic speed controller for sensored and sensorless motors is fine tuned for the today's high power brushless motors. Everything can be set-up on these controllers to provide you the best functionality and performance.
The CERIX II RS-160 "RACING FACTORY" is manufactured with the highest grade components to ensure the lowest possible internal resistance, resulting in optimized performance. The CERIX II RS-160 "RACING FACTORY" controller gives the 1/10 On-Road and 1/10 Off-Road competition racer what he needs. You will experience the best controllability of your 1/10 Racing Cars, no matter how you use it, with Spec or Modified motors
Features:
For sensored and sensorless motors
Manufactured with the highest grade components
Ultra compact design
Aluminum case for improved heat dissipation
Built in Capacitors
Built in power switch
Advanced boost and turbo timing system for improved acceleration performance
Enhanced throttle and brake control function.
10 programmed profiles can be stored in the ESC
Adjustable BEC voltage 6.0V 5A or 7.4V 5A Current
Powerful TC Link software to test motor timing and advise the best ESC timing setting
Programming Features:
General Settings
Running Mode
Cut-off Voltage
Overheat protection
Motor Rotation
Reverse Speed
Throttle Control
Dead Band
Punch Rate SW- Point
Punch Rate 1
Punch Rate 2
Throttle Curve
Brake Control
Initial Brake
Drag Brake
Brake Strength
Brake Rate Control
Brake Curve
Boost Function
Boost Timing
Start RPM
End RPM
Boost Constraint
Boost Slope
Turbo Timing
Turbo Timing
Activation Method
Turbo Delay
Start RPM
Turbo Slope
Power Specs:
Application: 1/10 Touring - 1/10 Pan Car - 1/10 Off-Road - Crawlers
Cont. Current (A): 160A
Burst (A): 800A
Nr of Li-xx Cells: 2 - 3S
BEC: 6V 5A or 7.4V 5A
Motor Type: Sensored - Sensorless
Motor Limits:
2S Li-Po
=> 3.5T - 1/10 On-Road
=> 5.5T - 1/10 Off-Road
3S Li-Po
=> 5.5T - 1/10 On-Road
=> 8.5T - 1/10 Off-Road
Resistance: 0.00018 ohm
Dimensions: 37x33x22mm (30mm Fan)
Weight: 43g (51g Fan)
The CERIX II RS-160 "RACING FACTORY" is manufactured with the highest grade components to ensure the lowest possible internal resistance, resulting in optimized performance. The CERIX II RS-160 "RACING FACTORY" controller gives the 1/10 On-Road and 1/10 Off-Road competition racer what he needs. You will experience the best controllability of your 1/10 Racing Cars, no matter how you use it, with Spec or Modified motors
Features:
For sensored and sensorless motors
Manufactured with the highest grade components
Ultra compact design
Aluminum case for improved heat dissipation
Built in Capacitors
Built in power switch
Advanced boost and turbo timing system for improved acceleration performance
Enhanced throttle and brake control function.
10 programmed profiles can be stored in the ESC
Adjustable BEC voltage 6.0V 5A or 7.4V 5A Current
Powerful TC Link software to test motor timing and advise the best ESC timing setting
Programming Features:
General Settings
Running Mode
Cut-off Voltage
Overheat protection
Motor Rotation
Reverse Speed
Throttle Control
Dead Band
Punch Rate SW- Point
Punch Rate 1
Punch Rate 2
Throttle Curve
Brake Control
Initial Brake
Drag Brake
Brake Strength
Brake Rate Control
Brake Curve
Boost Function
Boost Timing
Start RPM
End RPM
Boost Constraint
Boost Slope
Turbo Timing
Turbo Timing
Activation Method
Turbo Delay
Start RPM
Turbo Slope
Power Specs:
Application: 1/10 Touring - 1/10 Pan Car - 1/10 Off-Road - Crawlers
Cont. Current (A): 160A
Burst (A): 800A
Nr of Li-xx Cells: 2 - 3S
BEC: 6V 5A or 7.4V 5A
Motor Type: Sensored - Sensorless
Motor Limits:
2S Li-Po
=> 3.5T - 1/10 On-Road
=> 5.5T - 1/10 Off-Road
3S Li-Po
=> 5.5T - 1/10 On-Road
=> 8.5T - 1/10 Off-Road
Resistance: 0.00018 ohm
Dimensions: 37x33x22mm (30mm Fan)
Weight: 43g (51g Fan)
